Công Ty Duc Trung Steel chuyên Cung cấp và Nhập khẩu Thép Tấm, Thép Hình, Thép Ống, Thép Hộp, Thép Tròn Đặc xuất xứ từ nhiều nước khác nhau. Hàng hóa có đầy CO CQ khi Giao hàng.

Kích thước chuẩn (mm)				Diện tích mặt cắt ngang (cm2)	Đơn trọng (kg/m)	Momen quán tính (cm4)		Bán kính quán tính (cm)		Modun kháng uốn mặt cắt (cm3)
HxB	t1	t2	r	A	W	Ix	Iy	ix	iy	Zx	Zy
H100x100	6	8	10	21.9	17.2	383	134	4.18	2.47	76.5	26.7
H125x125	6.5	9	10	30.31	23.8	847	293	5.29	3.11	136	47
H150x75	5	7	8	17.85	14.0	666	49.5	6.11	1.66	88.8	13.2
H148x100	6	9	11	26.84	21.1	1,020	151	6.17	2.37	138	30.1
H150x150	7	10	11	40.14	31.5	1,640	563	6.39	3.75	219	75.1
H175x175	8	11	12	51.2	40.4	2,880	984	7.5	4.4	330	112
H198x99	4.5	7	11	23.18	18.2	1,580	114	8.26	2.21	160	23
H200x100	5.5	8	11	27.16	21.3	1,840	134	8.24	2.22	184	26.8
H194x150	6	9	13	39.01	30.6	2,690	507	8.3	3.61	277	67.6
H200x200	8	12	13	63.53	49.9	4,720	1,600	8.62	5.02	472	160
H200x204	12	12	13	71.5	56.2	4,980	1,700	8.35	4.88	498	167
H208x202	10	16	13	83.69	65.7	6,530	2,200	8.83	5.13	628	218
H248x124	5	8	12	32.68	25.7	3,540	255	10.4	2.79	285	41.1
H250x125	6	9	12	37.66	29.6	4,050	294	10.4	2.79	324	47
H244x175	7	11	16	56.2	44.1	6,120	984	10.4	4.18	502	113
H244x252	11	11	16	82.06	64.4	8,790	2,940	10.3	5.98	720	233
H248X249	8	13	16	84.7	66.5	9,930	3,350	10.8	6.29	801	269
H250x250	9	14	16	92.18	72.4	10,800	3,650	10.8	6.29	867	292
H250x255	14	14	16	104.7	82.2	11,500	3,880	10.5	6.09	919	304
H298x149	6	8	13	40.8	32.0	6,320	442	12.4	3.29	424	59.3
H300x150	7	9	13	46.78	36.7	7,210	508	12.4	3.29	481	67.7
H294X200	8	12	18	72.38	56.8	11,300	1,600	12.5	4.71	771	160
H298X201	9	14	18	83.36	65.4	13,300	1,900	12.6	4.77	893	189
H294X302	12	12	18	107.7	84.5	16,900	5,520	12.5	7.16	1,150	365
H298X299	9	14	18	110.8	87.0	18,800	6,240	13.0	7.5	1,270	417
H300x300	10	15	18	119.8	94.0	20,400	6,750	13.1	7.51	1,360	450
H300x305	15	15	18	134.8	106.0	21,500	7,100	12.6	7.26	1,440	466
H304X301	11	17	18	134.8	106.0	23,400	7,730	13.2	7.57	1,540	514
H310x305	15	20	18	165.3	130.0	28,150	9,460	13.2	7.6	1,810	620
H310x310	20	20	18	180.8	142.0	29,390	9,940	12.8	7.5	1,890	642
H346x174	6	9	14	52.68	41.4	11,100	792	14.5	3.88	641	91
H350x175	7	11	14	63.14	49.6	13,600	984	14.7	3.95	775	112
H354x176	8	13	14	73.68	57.8	16,100	1,180	14.8	4.01	909	134
H336x249	8	12	20	88.15	69.2	18,500	3,090	14.5	5.92	1,100	248
H340x250	9	14	20	101.5	79.7	21,700	3,650	14.6	6.0	1,280	292
H338x351	13	13	20	135.3	106.0	28,200	9,380	14.4	8.33	1,670	534
H344x348	10	16	20	146.0	115.0	33,300	11,200	15.1	8.78	1,940	646
H344x354	16	16	20	166.6	131.0	35,300	11,800	14.6	8.43	2,050	669
H350x350	12	19	20	173.9	137.0	40,300	13,600	15.2	8.84	2,300	776
H350x357	19	19	20	191.4	156.0	42,800	14,400	14.7	8.53	2,450	809
H396x199	7	11	16	72.16	56.6	20,000	1,450	16.7	4.48	1,010	145
H400x200	8	13	16	84.12	66.0	23,700	1,740	16.8	4.54	1,190	174
H404x201	9	15	16	96.16	75.5	27,500	2,030	16.9	4.6	1,360	202
H386x299	9	14	22	120.1	94.3	33,700	6,240	16.7	7.81	1,740	418
H390x300	10	16	22	136.0	107.0	38,700	7,210	16.9	7.28	1,980	481
H388x402	15	15	22	178.5	140.0	49,000	16,300	16.6	9.54	2,520	809
H394x398	11	18	22	186.8	147.0	56,100	18,900	17.3	10.1	2,850	951
H394x405	18	18	22	214.4	168.0	59,700	20,000	16.7	9.7	3,030	985
H400x400	13	21	22	218.7	172.0	66,600	22,400	17.5	10.1	3,330	1,120
H400x408	21	21	22	250.7	197.0	70,900	23,800	16.8	9.75	3,540	1,170
H406x403	16	24	22	254.9	200.0	78,000	26,200	17.5	10.1	3,840	1,300
H414x405	18	28	22	295.4	232.0	92,800	31,000	17.7	10.2	4,480	1,530
H428x407	20	35	22	360.7	283.0	119,000	39,400	18.2	10.4	5,570	1,930
H458x417	30	50	22	528.6	415.0	187,000	60,500	18.8	10.7	8,170	2,900
H498x432	45	70	22	770.1	605.0	298,000	94,000	19.7	11.1	12,000	4,370
H446x199	8	12	18	84.3	66.2	28,700	1,580	18.5	4.33	1,290	159
H450x200	9	14	18	96.76	76.0	33,500	1,870	18.6	4.4	1,490	187
H434x299	10	15	24	135.0	106.0	46,800	6,690	18.6	7.04	2,160	448
H440x300	11	18	24	157.4	124.0	56,100	8,110	18.9	7.18	2,550	541
H496x199	9	14	20	101.3	79.5	41,900	1,840	20.3	4.27	1,690	185
H500x200	10	16	20	114.2	89.6	47,800	2,140	20.5	4.33	1,910	214
H506x201	11	19	20	131.3	103.0	56,500	2,580	20.7	4.443	2,230	254
H482x300	11	15	26	145.5	114.0	60,400	6,760	20.4	6.82	2,500	451
H488x300	11	18	26	163.5	128.0	71,000	8,110	20.8	7.04	2,910	541
H596x199	10	15	22	120.5	94.6	68,700	1,980	23.9	4.05	2,310	199
H600x200	11	17	22	134.4	106.0	77,600	2,280	24.0	4.12	2,590	228
H606x201	12	20	22	152.5	120.0	90,400	2,720	24.3	4.22	2,980	271
H612x202	13	23	22	170.7	134.0	103,000	3,180	24.6	4.31	3,380	314
H582x300	12	17	28	174.5	137.0	103,000	7,670	24.3	6.63	3,530	511
H588x300	12	20	28	192.5	151.0	118,000	9,020	24.8	6.85	4,020	601
H594x302	14	23	28	222.4	175.0	137,000	10,600	24.9	6.9	4,620	701
H692x300	13	20	28	211.5	166.0	172,000	9,020	28.6	6.53	4,980	602
H700x300	13	24	28	235.5	185.0	201,000	10,800	29.3	6.78	5,760	722
H708x302	15	28	28	273.6	215.0	237,000	12,900	29.4	6.86	6,700	853
H792x300	14	22	28	243.4	191.0	254,000	9,930	32.3	6.39	6,410	662
H800x300	14	26	28	267.4	210.0	292,000	11,700	33.0	6.62	7,290	782
H808x302	16	30	28	307.6	241.0	339,000	13,800	33.2	6.7	8,400	915
H890x299	15	23	28	270.9	213.0	345,000	10,300	35.7	6.16	7,760	688
H900x300	16	28	28	309.8	243.0	411,000	12,600	36.4	6.39	9,140	843
H912x302	18	34	28	364.0	286.0	498,000	15,700	37.0	6.56	10,900	1,040
H918x303	19	37	28	391.3	307.0	542,178	17,222	37.2	6.63	11,800	1,140

Mác thép	Mác cũ	C (%)	Si (%)	Mn (%)	P (%) ≤	S (%) ≤	Điều kiện kèm theo
Thép cacbon thông thường [JIS G3101 (1981)]							Kết cấu thép độ dày (mm) ≤ 50 >50 ~ 200
SS330	S34	-	-	-	0.050	0.050
SS400	S41	-	-	-	0.050	0.050
SS490	SS50	-	-	-	0.050	0.050
SS540	SS55	≤ 0.30	-	1.60	0.040	0.040
Thép kết cấu hàn [JIS G3106 (1992)]
SM400A	SM41A	≤ 0.23 ≤ 0.25	- -	≥ 2.5 X C ≥ 2.5 X C	0.035 0.035	0.035 0.035
SM400B	SM 41B	≤ 0.20 ≤ 0.22	≤ 0.35 ≤ 0.35	0.60 ~ 1.00 0.60 ~ 1.00	0.035 0.035	0.035 0.035	≤ 50 >50 ~ 200
SM400C	SMC	≤ 0.18	≤ 0.35	≤ 1.4	0.035	0.035	≤ 100
SM490A	SM50A	≤ 0.20	≤ 0.55	≤ 1.60	0.035	0.035	≤ 50
SM490A	SM50A	≤ 0.22	≤ 0.55	≤ 1.60	0.035	0.035	> 50 ~ 200
SM490B	SM50B	≤ 0.18	≤ 0.55	≤ 1.60	0.035	0.035	≤ 50
		≤ 0.22	≤ 0.55	≤ 1.60	0.035	0.035	> 50 ~ 200
SM490C	SM50C	≤ 0.18	≤ 0.55	≤ 1.60	0.035	0.035	≤ 100
SM490YA	SM50YA	≤ 0.20	≤ 0.55	≤ 1.60	0.035	0.035	≤ 100
SM490YB	SM50YB	≤ 0.20	≤ 0.55	≤ 1.60	0.035	0.035	≤ 100
SM520B	SM53B	≤ 0.20	≤ 0.55	≤ 1.60	0.035	0.035	≤ 100
SM520C	SM53C	≤ 0.20	≤ 0.55	≤ 1.60	0.035	0.035	≤ 100
SM570(1)	SM58	≤ 0.18	≤ 0.55	≤ 1.60	0.035	0.035	≤ 100
(1) Hàm lượng cacbon (Ce) của mác thép SM570, chiều dày ≤ 50mm là ≤ 0.44%, từ 50 - 100mm ≤ 0.47%
